Instruction:
1. mainly used for single straw packing and connecting package.
2. Compact structure,stable performance and simple operation.
3. Servo system control,intelligent, bag length is set ,cut, no need to adjust the air, one step,save the province.
4. Industrial touch screen display,large screen interactive system,parameter setting convenient,at a glance.
5. Intelligent discharge detection,optimization of online function ,effectively prevent the loss of materials and packaging materials.
型号 | Model | MW-4310 |
单只包包装机 Wrapping Machine | ||
印刷部分 | Printing Unit | No |
吸管外径 | Straw outer diameter | 5-12mm |
长度 | Length | 180-260mm ， Controlled by PLC , PLC控制长度 |
产量 | Capacity | 400-600pcs/min |
功率 | Power | 1.85kw ，220v，1phase |
外形尺寸 | Dimension | 2x1.5x1.5m |
重量 | Weight | 360kgs |
大包包装机 Film Packing Machine | ||
最大卷膜宽度 | Film max-width | 560mm |
最大包装产品数量 | Max Packing Quantity | 300pcs |
包装膜厚度 | Film thickness | 0.012-0.06mm |
包装速度 | Packing speed | 5-10pcs /min |
吸管内径 | Paper straw Diameter | φ6mm-12mm |
吸管长度 | Paper Straw length | 180-260mm |
生产线外形尺寸 | Packing line dimensions | 2500mm*1300mm*1300mm |
净重量 | Weight | 300kg |
整机功率 | Power | 3.0kw |
整机重量 | Weight | 660kg |
