Application：
Be applied to packing circle drinking straws,tubes,pipes(straight not bend).such as plastic drinking
straws,paper drinking straws,or drinking straws of milk tea ,coffee,coke,soybean and so on.
Scope of Application:
This machine is suitable for packing groups drinking straws , incense sticks ,pencil in one bag , 5-300pcs can be packed together according to various diameter.
Features :
1．Human-Machine Interface in English, adopt touch screen.
2．Bag length can be set in touch screen and cut in one step.
3．Adopt high accuracy photocell tracking systems.
4. Automatic counting function.
5．Bag length detect automatically , easy to operate.
Specifications:
Model | MW-SSDFC |
Max. film width | 530mm |
Packing Speed(Adjustable) | 3-20 bag/min |
Film thickness | 0.03-0.06mm |
Bag Length | 60–600mm |
Bag Width | 80–250mm |
Straw quantity | 5-300pcs |
Power Supply | 220V , 50/60 Hz , 3 KW, 1 Phase |
Machine Size (L x W x H) | 3000 × 1400 x 1400 mm |
Machine Weight | 550 Kg |
Main electrical parts:
Name | Model | Quantity | Brand |
Touch screen | TK6071iQ | 1 | Weinview |
PLC | FP-X0 L30R | 1 | Panasonic |
Servo motor | HJ-KS73J | 1 | Mitsubishi |
Relay | RXM2LB2BD | 7 | Schneider |
Air switch | C25/C10 | 1/5 | Schneider |
Power supply | ABL2REM24015H | 1 | Schneider |
Valve | 1 Set | Jelpc | |
Photoelectric switch | Z3N-TB22 | 1 | Julong |
