2 Color Roll Coated Paper Flexographic Printing Machinery

Introduce sensitization resin as flexible printing plate. It is a kind of ideal printing equipment for producing paper packing bag for good, supermarket handbag, vest bag and clothes bag,etc.

Printing materials as following:
1.Polyethylene, polyethylene plastic film printing
2.Bag(packing bag for food, supermarket handbag, vest bag and clothes bag printing
3.Roller paper and craft paper printing
4.Pp woven bag , pvc film, bopp film, printing
5.Laminated bag rolling printing
6.Non woven rolling printing
7.Rice bag pp woven printing
8.Paper printingNote:Different printing material , machine some parts design different. Pls kindly show Printing material when inquiry.

Main Features & Advantages

Sp

Model	MW2-600	MW2-800	MW2-1000	MW2-1200	MW2-1400	MW2-1600
Max. Material width	650mm	850mm	1050mm	1250mm	1450mm	1650mm
Max. Printing width	560mm	760mm	960mm	1160mm	1360mm	1560mm
Printing color	2+0, 1+1
Printing length	7.5''-40''(190-1060mm)
Printing cylinder way	Hydraulic control up and down
Drive type	Helical gear drive
Mechanical speed	90m/min
Printing speed	10-70m/min
Anilox roller	(1) Metal anilox roller:100-300LPI (2) Ceramic anilox roller: Shanghai murata brand 200-800LPI and Open type doctor blade
Tension system	Automatic tension controller
EPC	Web guide 1pcs
Register precision	Longitudinal:±0.25mm crosswise:±0.25mm;
Color register	By manual
Unwind/rewind dia.	Φ1200mm
Material holder	Air shaft 3'', 2pcs
Dry system	Electric heating
Machine power	14kw	16kw	18kw	20kw	24kw	26kw
Machine size (L x W x H)	5.0×2.0×2.3m	5.0×2.2×2.3m	5.0×2.4×2.3m	5.0×2.6×2.3m	5.0×2.8×2.3m	5.0×3.0×2.3m
Machine weight	2800Kg	3000 Kg	3200 Kg	3400 Kg	3500 Kg	3800 Kg
