Purpose:
Applicable to slitting of BOPP sealing tape/glass paper tapes used in Europe, America, Japan, and Korea (low-noise and environment-friendly type).
Features:
Fully automatic alternately winding with four axes and continuous winding, which and promote work efficiency.
Inverter step less speed regulation, provided with 3-section counter, with which automatic deceleration for stopping is possible during high-speed operation.
Unwinding tension controlled with pneumatic brake; winding tension adopts dual control, provided with clutch and independent sliding unit for unwinding axis that can adjust the tension freely.
Provided with curved stretch roll that can effectively stretch the base material.
Provided with automatic labeling function, flat-cable-type edge rewinding function, low-noise tape processing and forming function.
Main technical:
Type | MW-SRD1300 |
Max. Width of Mother Roll | 1300mm |
Max. Diameter of Mother Roll | 600mm |
Width of Final Roll | 8-500mm |
Max. Diameter of Rewinding | 50mm |
Internal Diameter of Roll Core | 25.4mm |
Slitting and Rewinding Speed | 10-200m/min |
Tolerance of EPC | ±0.5mm |
Total Power | 3.75kw |
Weigh t o f Machine | 1200kg |
Overall Dimension(L×W×H) | L2500×W2400×H1650mm |
