Feature :
This machine is suitable for blank adhesive labels. Die-cutting. Laminating (option).slitting can be finished in one process. It has the function of automatic meter counting. automatic stop. web guiding by photocell, The ma-chine has the characteristic of compact structure. fast speed. high efficiency. easy operation. accurate slitting and steady running etc.
Main technical parameter :
Model | MW-SA320 |
Slitting speed： | 80m/min |
Die-Cutting speed： | 70m/min |
Die-Cutting Repeat Length： | 177-476mm |
Max. web . width： | 320mm |
Max unwinding diameter： | 500mm |
Max rewinding diameter： | 480mm |
Overall diameters： | 1.95mX1.25mX1.75m |
Machine weight： | 1000kgs |
Main Ports:
Name | Power | Quantity | Place Of Production |
Main Motor | 2.2KW | 1set | China |
Inverter | 3KW | 1set | HuNan |
Web Guide | 1set | GuangDong | |
Air Blower | 0.55 KW | 1set | China |
Air Shaft | 3Inch | 3pcs | RuiAn |
Knife | 6sets | AnHui | |
Led Lamp | 3w | 1set | China |
Switch Button | 10-16sets | Schneider | |
Low Voltage Electrical | ChinaZhengtai | ||
Magnetic powder brake | 2.5kgs | 1set | RuiAn |
Magnetic powder clutch | 2.5kgs | 2sets | RuiAn |
Magnetic powder controller | 3sets | China |
Feature :
This machine is suitable for blank adhesive labels. Die-cutting. Laminating (option).slitting can be finished in one process. It has the function of automatic meter counting. automatic stop. web guiding by photocell, The ma-chine has the characteristic of compact structure. fast speed. high efficiency. easy operation. accurate slitting and steady running etc.
Main technical parameter :
Model | MW-SA320 |
Slitting speed： | 80m/min |
Die-Cutting speed： | 70m/min |
Die-Cutting Repeat Length： | 177-476mm |
Max. web . width： | 320mm |
Max unwinding diameter： | 500mm |
Max rewinding diameter： | 480mm |
Overall diameters： | 1.95mX1.25mX1.75m |
Machine weight： | 1000kgs |
Main Ports:
Name | Power | Quantity | Place Of Production |
Main Motor | 2.2KW | 1set | China |
Inverter | 3KW | 1set | HuNan |
Web Guide | 1set | GuangDong | |
Air Blower | 0.55 KW | 1set | China |
Air Shaft | 3Inch | 3pcs | RuiAn |
Knife | 6sets | AnHui | |
Led Lamp | 3w | 1set | China |
Switch Button | 10-16sets | Schneider | |
Low Voltage Electrical | ChinaZhengtai | ||
Magnetic powder brake | 2.5kgs | 1set | RuiAn |
Magnetic powder clutch | 2.5kgs | 2sets | RuiAn |
Magnetic powder controller | 3sets | China |
