| Quantity: | |
|---|---|
Material Of Paper: | Kraft paper, textile spool paper, art post paperboard, etc |
Thickness | 80-600gsm |
Unwind Width: | 600mm - 1600mm |
Unwind Diameter: | 1200mm (Max.) |
Rewind Diameter: | 1200mm(Max.) |
Rewind Mini Width: | 40mm(Min.) |
Slitting Speed: | 250m/min |
Speed Regulation： | Regulation motor |
Loading Way: | Shaft less loading |
Clamping Way: | clamping automatically by motor |
Rewinding Shaft | Air shaft |
Discharging Way: | By pneumatic |
Voltage | 380V50HZ |
Size | |
Overall Dimension: | 2900*3300*1250mm |
Weight | 3100KGS |
Main Parts | |
Base Paper Chuck: | 3inches 1Pair |
Discharging Pneumatic Cylinder: | 2 sets |
Material Shafts Braking Device: | 2 sets |
Material Lifting Device: | 1 set |
Material Clamping Device: | 2 sets |
Independent Electric Operating Box: | 1 set |
Blade: | 20 groups |
Control System | |
Main Motor: | CHINA DEDONG 7.5KW*1 |
Lifting Motor: | CHINA XINLING 1.5KW*1 |
Clamping Motor: | CHINA XINGLING1.5KW*1 |
Working Air Pressure: | 0.6Mpa |
Signal Component | CHINA HUGONG |
Pneumatic Component: | CHINA XINGCHEN |
Electrical Equipment: | DELIXI |
Bearing | CHINA HAERBING |
Knife Holder Lift Type | By motor |
Spare Parts And Professional Tools | |
Allen Wrench: | 1 piece |
Open-End Wrench: | 1 piece |
Useful Tools: | 1 set |
Air Gun: | 1 piece |
Blade: | 3 pieces |
Three-Way Connection: | 1 piece |
Air Tube: | 8 meters |
Limit Switch: | 1 piece |
