Feature:
Rack structure: the main wall and some profiles, for the split connection structure, in the cutting knife position and the location of the material with a step board, easy to operate;
Discharge rack a group, with Ф74 air shaft;
Automatic correction (hydraulic correction device);
Equipped with a rolling-type roller for spreading wrinkles;
Traction device: with a set of steel roller;
Punching device: using a screwdriver to fight the dotted line, punching pitch adjustable, with 1: 3 chain transmission adjustment (long section 200-600mm);
Slitting device: the use of gas slitting device, cut the end of the neat, cut the width of the task adjustable;
In the rewinding part is equipped with pneumatic pressure roller, used to adjust the winding tightness;
Surface coiling, rewinding in the middle of two rewinding rolls;
Reel roller: one for the anti-skid roller, the other and for the cutting knife;
Mechanical capacity: 0-200 m / min;
Host power: 4KW;
Frequency;
Automatic counting
Manual, automatic servo motor control synchronous discharge;
Catheter with aluminum alloy material, no resistance, good guide;
Main Technical :
How it works: Pneumatic feeding -Servo motor control - Traction - Dot - Slitting - Rewinding - Releasing finished |
Material specifications: 160x Ф1000mm (30-100 grams of spunlace non-woven); |
Raw material roll core: Ф76mm; |
Reel roll width: <1600mm; |
Slitting width: ≥ 70mm (blades 16); |
Product Roll diameter: ≤ 400mm; |
Total power 12kw |
Production speed of 200 m / min (depending on the specific characteristics of the material ) |
Machine size : Length 3000mm × width 2500mm × height 1600mm |
| Equipment weight： 2300kg |
