Application
The machine is used for cutting paper core
Feature :
1 knife shaft adopts the belt transmission, the power transmission efficiency is high, the noise is low.
2 Rotary blade with safety protection cover, to ensure the safety of the operator.
3 This machine adopts mechanical cutting depth control, cutting deep space is accurate, practical, easy to operate.
4 with automatic paper tube unloading
Main technical:
Max cutting width: | 500mm |
Min cutting width: | 10mm |
Paper core inner diameter | 25-76mm |
Paper core thickness: | 2-6mm |
Motor: | 1.1kw |
Power supply: | 220V, 1P, 50Hz |
Air: | 5kg/cm2 |
Weight: | 450kg |
Packing dimensions: | 1800 x 650 x 1300mm |
